24G Radar Presence Sensor (RS485)
No.R1-24G-485
SKU: 60.10.2208
Product Model: CTL-SEN-R1/2208
Accurate detection of static and minor motion states
This sensor uses a 24GHz millimeter-wave radar to detect human presence. It adds a life detection algorithm to the existing Creatrol algorithm, offering enhanced anti-interference capabilities and increased detection precision. It also features a built-in 0-32,000 Lux illuminance meter chip, with independently adjustable sensitivity and detection range.
Installation Height: 2~4m (Ceiling)
Detection Angle: 360°
Detection Range: φ8m (at 3m height)
Illuminance Sensor: 0~32000 Lux
Cut-out Size: φ42mm
Power Input: DC12~30V
Interface: RS485
Accurate detection of static and minor motion states
This sensor uses a 24GHz millimeter-wave radar to detect human presence. It adds a life detection algorithm to the existing Creatrol algorithm, offering enhanced anti-interference capabilities and increased detection precision. It also features a built-in 0-32,000 Lux illuminance meter chip, with independently adjustable sensitivity and detection range.
Installation Height: 2~4m (Ceiling)
Detection Angle: 360°
Detection Range: φ8m (at 3m height)
Illuminance Sensor: 0~32000 Lux
Cut-out Size: φ42mm
Power Input: DC12~30V
Interface: RS485
